1241.1113.7049 | SCHURTER
Short-stroke pushbutton, Form A (N/O), 125 mA/48 VDC, unlit , actuator (black), 3 N, solder connection, 1241.1113.7049
Unit Price (€ / pc.)
4.8671 € *
Available: 0 pcs.
Leadtime: 11 Weeks **
Total Price:
4.87 € *
Price list
Quantity
Price per unit*
1 pcs.
4.8671 €
10 pcs.
4.4268 €
50 pcs.
3.9865 €
100 pcs.
3.5819 €
*incl. VAT plus shipping costs
**Subject to prior sale
Membrane switch, 1241.1113.7049, SCHURTER
The 1241.1113.7049 membrane switch is a unique mechanical switch with tactile feedback, a small mounting depth, and a high lifetime of 5 million actuations.
Technical specifications
| Anschluss | Lötanschluss | |
| beleuchtet | No | |
| Betätigungskraft | 3 N | |
| Farbe Betätiger | schwarz | |
| Höhe | 13 mm | |
| Kontaktmaterial | versilbert | |
| Länge | 18 mm | |
| Schaltfunktion | Schließer | |
| Schaltleistung | 125 mA/48 VDC |
Download
Logistics
| Ursprungsland | CZ |
| Zolltarifnummer | 85365011 |
| MSL | MSL 1 |
| Originalverpackung | Karton mit 100 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
