3SB2000-2HE01 | Siemens
Selector switch, unlit, latching, waistband round, green, front ring black, 90°, trigger position 0 + 1, mounting Ø 16 mm, 3SB2000-2HE01
Order No.: 80P7207
EAN: 4011209210608
MPN:
3SB2000-2HE01
3SB20002HE01
Unit Price (€ / pc.)
20.2895 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Selector switch, 16 mm, round, plastic, green, 2 switch positions O-I, latching, actuating angle 90 degree Selector switches SIRIUS 3SB2 for switching and controlling electrical loads.
Technical specifications
| Version | toggle switch | |
| Type of mounting | front panel mounting | |
| can be illuminated | No | |
| Collar shape of the front frame | round | |
| Rotation angle | 90° | |
| Installation diameter | 16 mm | |
| Installation height | 17 mm | |
| Installation depth | 50 mm | |
| Actuator colour | green | |
| Front ring colour | black | |
| Contact function | latching | |
| Protection class | IP65 | |
| Trigger position key | 0 + 1 |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85389099 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
