3ND1817 | Siemens
NH fuse NH000, 40 A, aM, 440 V (DC), 500 V (AC), 120 kA breaking capacity, 3ND1817
Order No.: 27H2473
EAN: 4001869020297
MPN:
3ND1817
3ND1817
Unit Price (€ / pc.)
15.2082 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
15.21 € *
Price list
Quantity
Price per unit*
1 pcs.
15.2082 €
3 pcs.
14.9107 €
*incl. VAT plus shipping costs
**Subject to prior sale
LV HRC fuse element, NH000, In: 40 A, aM, Un AC: 500 V, Un DC: 440 V, Front indicator, live grip lugs LV HRC fuse link SENTRON 3ND for switching device protection in motor circuits.
Technical specifications
| Ausführung | NH-Sicherung | |
| Auslösecharakteristik | aM | |
| Ausschaltvermögen | 120 kA | |
| Bauform | NH000 | |
| Breite | 21 mm | |
| Gehäuse | Keramikrohr | |
| Höhe | 80 mm | |
| Länge | 53 mm | |
| Nennspannung (AC) | 500 V | |
| Nennspannung (DC) | 440 V | |
| Nennstrom | 40 A |
Download
Logistics
| Ursprungsland | GR |
| Zolltarifnummer | 85361050 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
