3NE4334-6B | Siemens
Semiconductor protective fuse, 500 A, aR, 440 V (DC), 800 V (AC), 100 kA breaking capacity, 3NE4334-6B
Unit Price (€ / pc.)
176.6436 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
176.64 € *
Price list
Quantity
Price per unit*
1 pcs.
176.6436 €
3 pcs.
173.1926 €
*incl. VAT plus shipping costs
**Subject to prior sale
SITOR fuse link, with female thread on both sides, In: 500 A, aR, Un AC: 800 V, Un DC: 440 V, front indicator Fuses for stringent requirements in photovoltaic applications. Siemens photovoltaic fuses are especially designed for protecting PV modules and ensure a high level of plant availability over the entire life of the PV system. The fuses have a high DC rated voltage and withstand the greatest temperature fluctuations without damage. All Siemens photovoltaic fuse systems therefore comply with the standard IEC 60269-6.
Features
- Reliable protection of the modules and the module connection cables in the event of reverse currents
- Compliance with the UL standard UL 2579 (for IEC cylindrical fuses)
- Safe tripping in case of residual currents and therefore reduction of the risk of fire due to DC electric arcs
- Safe separation when the fuse holder/fuse base is open
- Long service life despite frequent and very variable load currents
Technical specifications
| Ausführung | Halbleiterschutzsicherung | |
| Auslösecharakteristik | aR | |
| Ausschaltvermögen | 100 kA | |
| Breite | 60 mm | |
| Gehäuse | Keramikrohr | |
| Höhe | 77 mm | |
| Länge | 60 mm | |
| Nennspannung (AC) | 800 V | |
| Nennspannung (DC) | 440 V | |
| Nennstrom | 500 A |
Download
Logistics
| Ursprungsland | GR |
| Zolltarifnummer | 85361090 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
