3NE5334-0MK06 | Siemens
NH fuse NH2, 500 A, aR, 1 kV (DC), 1.5 kV (AC), 3NE5334-0MK06
Unit Price (€ / pc.)
270.7012 € *
Available: 0 pcs.
Leadtime: On Request **
SITOR fuse link, with slotted blade contacts, NH2, In: 500 A, aR, Un AC: 1500 V, Un DC: 1000 V, without Indicator Fuses for stringent requirements in photovoltaic applications. Siemens photovoltaic fuses are especially designed for protecting PV modules and ensure a high level of plant availability over the entire life of the PV system. The fuses have a high DC rated voltage and withstand the greatest temperature fluctuations without damage. All Siemens photovoltaic fuse systems therefore comply with the standard IEC 60269-6.
Features
- Reliable protection of the modules and the module connection cables in the event of reverse currents
- Compliance with the UL standard UL 2579 (for IEC cylindrical fuses)
- Safe tripping in case of residual currents and therefore reduction of the risk of fire due to DC electric arcs
- Safe separation when the fuse holder/fuse base is open
- Long service life despite frequent and very variable load currents
Technical specifications
| Version | NH fuse | |
| Tripping characteristics | aR | |
| Design | NH2 | |
| Enclosure | ceramic tube | |
| Rated voltage (AC) | 1.5 kV | |
| Rated voltage (DC) | 1 kV | |
| Rated current | 500 A |
Download
Logistics
| Country of origin | GR |
| Customs tariff number | 85361090 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
