3UG4501-1AW30 | Siemens
Monitoring relays, analog, resistance monitoring from 2-200 kΩ, 1 Form C (NO/NC), 240 V (DC), 240 V (AC), 3UG4501-1AW30
Order No.: 27H8954
EAN: 4011209665309
MPN:
3UG4501-1AW30
3UG45011AW30
Unit Price (€ / pc.)
117.5244 € *
Available: 0 pcs.
Leadtime: 1 Week **
Analog monitoring relay Fill level monitoring Resistance monitoring from 2 to 200 kohm overshoot and undershoot 24 to 240 V AC/DC 50 to 60 Hz DC and AC 2-step or 1-step control Tripping delay 0.5 to 10 s 1 change-over contact screw terminal Successor product for 3UG3501 Level monitoring relay with analog setting SIRIUS 3UG4 for level monitoring of conductive fluids to protect against overflow, dry running or leakage.
Technical specifications
| Connection | screw connection | |
| Version | analog, resistance monitoring from 2-200 kΩ | |
| Contact type | 1 Form C (NO/NC) | |
| Coil voltage (AC) | 240 V | |
| Coil voltage (DC) | 240 V |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85364900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | lead, lead monoxide (lead oxide), Dicyclohexyl phthalate |
