61.7580-10028 | Stäubli Electrical Connectors

Coaxial cable, 45 Ω, SILI-SC 0.5/1.0, gray

Order No.: 96F922
EAN: 4099891758813
MPN:
61.7580-10028
61.7580-28
Series: Cableline
61.7580-10028 Stäubli Electrical Connectors Coaxial Cables
Image may differ
Unit Price (€ / mtr.)
7.7350 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
7.74 € *
Price list
Quantity
Price per unit*
1 mtr.
7.7350 €
10 mtr.
7.1638 €
50 mtr.
6.5807 €
100 mtr.
6.1999 €
500 mtr.
5.8191 €
*incl. VAT plus shipping costs
**Subject to prior sale

Coaxial cable, 61.7580-10028, Stäubli Electrical Connectors

Shielded, highly flexible coaxial cable. Inner core stranded Cu, shield Cu mesh. Core insulation and outer insulation silicone with high temperature resistance.

Technical specifications
Outer diameter 4.9 mm
Colour grau
Impedance 45 Ω
Cable structure 256 x 0,05 mm
Cable material Kupfer
max. operating temperature 150 °C
min. operating temperature -80 °C
Shielding geschirmt
Logistics
Country of origin DE
Customs tariff number 85442000
Original Packaging Rolle mit 100 Meter
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
