64.1021-25 | Stäubli Electrical Connectors

4 mm jack, solder connection, 2.5 mm², green, 64.1021-25

Order No.: 25F1004
EAN: 4099889671087
MPN:
64.1021-25
K-41/A GRÜN
Series: K-41/A
Stäubli Electrical Connectors
64.1021-25 Stäubli Electrical Connectors Laboratory Connectors
Image may differ
Print
Key Specification:
Version jack
diameter 4 mm
Colour green
Connection solder connection
contact surface gold-plated
Show 8 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
1.7731 € *
Available: 58 pcs.
Leadtime: 2 Weeks **
Total Price:
1.77 € *
Price list
Quantity
Price per unit*
1 pcs.
1.7731 €
25 pcs.
1.5113 €
100 pcs.
1.3923 €
500 pcs.
1.3328 €
1000 pcs.
1.2138 €
*incl. VAT plus shipping costs
**Subject to prior sale
Description
Technical specifications
Download
Logistics
Compliance
Variations

4 mm Jack, 64.1021-25, Stäubli Electrical Connectors

Ø 4 mm rigid, for self-assembly of test leads.
Technical specifications
Connection solder connection
Version jack
Rated Voltage 30 VAC/60 VDC
Rated current 32 A
Touch safe No
diameter 4 mm
Colour green
contact surface gold-plated
Length 50 mm
Cable cross-section 2.5 mm²
max. Cable diameter 3.9 mm
Show similar products 0
Logistics
Country of origin DE
Customs tariff number 85369010
Original Packaging Bag with 25 pieces
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free No
Substance description Lead
