64.1045-22 | Stäubli Electrical Connectors
4 mm plug, screw connection, 2.5 mm², red, 64.1045-22
Unit Price (€ / pc.)
2.8679 € *
Available: 277 pcs.
Leadtime: 3 Weeks **
Total Price:
2.87 € *
Price list
Quantity
Price per unit*
1 pcs.
2.8679 €
10 pcs.
2.5228 €
100 pcs.
2.2134 €
500 pcs.
2.1420 €
1000 pcs.
1.9873 €
*incl. VAT plus shipping costs
**Subject to prior sale
Single plug, 64.1045-22, Stäubli Electrical Connectors
Stackable, Ø 4 mm, with spring-loaded MULTILAM, for self-assembly of test leads. Screw connection.
Technical specifications
| Anschluss | Schraubanschluss | |
| Ausführung | Stecker | |
| Bemessungsspannung | 30 VAC/60 VDC | |
| Bemessungsstrom | 32 A | |
| Berührungssicher | No | |
| Durchmesser | 4 mm | |
| Farbe | rot | |
| Kontaktoberfläche | vergoldet | |
| Länge | 54.3 mm | |
| Leiterquerschnitt | 2,5 mm² | |
| max. Kabeldurchmesser | 3.9 mm | |
| Stapelbar | Yes |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
| Originalverpackung | Beutel mit 100 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
