66.9126-25 | Stäubli Electrical Connectors
Adapter, cable lug 8.2 mm to 4 mm socket, green, CAT II, 66.9126-25
Unit Price (€ / pc.)
4.7005 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
4.70 € *
Price list
Quantity
Price per unit*
1 pcs.
4.7005 €
10 pcs.
4.1293 €
50 pcs.
3.6295 €
100 pcs.
3.4986 €
500 pcs.
3.2606 €
*incl. VAT plus shipping costs
**Subject to prior sale
Cable lug adapter, 66.9126-25, Stäubli Electrical Connectors
Made of brass for permanent installation, for example, for connecting screw terminals. Ø 4 mm rigid socket in insulator accepting spring-loaded Ø 4 mm plugs with rigid insulating sleeve. Fork lug can be bent once to 45°. Color: green.
Technical specifications
| Version | Adapter | |
| Rated Voltage | 1000 V | |
| Rated current | 20 A | |
| Colour | grün | |
| contact surface | vernickelt | |
| Rated category | CAT II | |
| Site (1) | Kabelschuh 8,2 mm | |
| Site (2) | 4 mm Buchse |
Download
Logistics
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Blei |
