SHV12-1A85-78L4K | Standex Electronics
Reed relay, 12 V (DC), 1 Form A (N/O), SIP, 100 W, SHV12-1A85-78L4K
Unit Price (€ / pc.)
10.4244 € *
Available: 0 pcs.
Leadtime: On Request **
Reed Relay, SHV12-1A85-78L4K, Meder
Coil voltage: 12VDC, contact type: 1 NO (SPST-NO), rated power: 100 W, switching current: 1A, breakdown voltage: 4kv
Technical specifications
| Anschluss | Leiterplattenanschluss | |
| Bauform | SIP | |
| Kontaktart | 1 Schließer | |
| Schaltleistung | 100 W | |
| Schaltspannung (AC) | 1 kV | |
| Schaltspannung (DC) | 1 kV | |
| Schaltstrom | 1 A | |
| Spulenspannung (DC) | 12 V | |
| Spulenwiderstand | 500 Ω |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85364110 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
