MF25101V2-1000U-A99 | SUNON
DC axial fan, 12 V, 25 x 25 x 10 mm, 5.09 m³/h, 16 dB, vapo, SUNON MF25101V2-1000U-A99
Unit Price (€ / pc.)
10.0436 € *
Available: 0 pcs.
Available in 4 Days: 871 pcs.
Leadtime: 18 Weeks **
Total Price:
10.04 € *
Price list
Quantity
Price per unit*
1 pcs.
10.0436 €
10 pcs.
8.8417 €
50 pcs.
8.2467 €
150 pcs.
7.8778 €
500 pcs.
7.4732 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC Axial fan, MF25101V2-1000U-A99, SUNON
The MF25101V2-1000U-A99 DC axial fan use MagLev to increase performance, durability and reduce noise. Magnetic levitation technology eliminates the need for shaft to bearing contact to ensure friction free operation.
Features
- Insulution resistance 10 ohm minimum at 500 VDC
- Precision vapo bearing system
- Single phases, 4 poles brushless DC motor
- Material of frame thermoplastic PBT
Technical specifications
| Version | DC axial fan | |
| Width | 25 mm | |
| speed | 9600 1/min | |
| Height | 25 mm | |
| Type of bearing | vapo | |
| Power consumption | 0.36 W | |
| Rated voltage | 12 V | |
| Sound pressure level | 16 db | |
| Depth | 10 mm | |
| Volume flow | 5.09 m³/h |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 84145925 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
