70045K | Talema

Name: Toroidal flat transformer, 10 VA, 22 V, 22 V, 2x115 V, Talema 70045K
Brand: Talema
SKU: 38C790
Price: 31.54 EUR
Availability: InStock

Toroidal flat transformer, 10 VA, 22 V, 22 V, 2x115 V, Talema 70045K

Order No.: 38C790

EAN: 4099891351021

MPN:

70045K

Series: 700

70045K Talema Toroidal Transformers Image 2

Image may differ

Key Specification:

Ausgangsleistung 10 W

Primärspannung 2 x 115 V

Sekundärspannung (1) 22 V

Sekundärspannung (2) 22 V

Ordering Information:

Lieferung inklusive Montagezubehör

Show 20 variants

Download Datasheet Technical specifications

Unit Price (€ / pc.)

31.5350 € *

Available: 93 pcs.

Leadtime: On Request **

Total Price:

31.54 € *

Price list

Quantity

Price per unit*

1 pcs.

31.5350 €

5 pcs.

29.6548 €

15 pcs.

28.5124 €

50 pcs.

27.2510 €

150 pcs.

26.1205 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Toroidal low-profile transformers, with UL certification, type Talema 700.

For ultra compact space and weight saving installation, excellent temperature response and only minute leakage field

Rated power 10 VA, type 7004.

Download

Technisches Datenblatt - EN Technisches Datenblatt

Konformitätsdeklaration - EN Konformitätsdeklaration

Herstellerkatalog - EN Herstellerkatalog

Technisches Datenblatt - DE Technisches Datenblatt

Konformitätsdeklaration - DE Konformitätsdeklaration

Logistics

Ursprungsland	IN
Zolltarifnummer	85043180

Compliance

RoHS konform	Yes
Stand der RoHS-Richtlinie	3/31/15
SVHC frei	Yes

1 item in 20 variations
