B43544B2108M067 | TDK (EPCOS)
Electrolytic capacitor, 1000 µF, 200 V (DC), ±20 %, radial, pitch 10 mm, Ø 30 mm, B43544B2108M067
Unit Price (€ / pc.)
4.6886 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Electrolytic capacitor, B43544B2108M067, EPCOS
Aluminum electrolytic capacitor - Snap-in capacitor
Features
- Extremely high CV product, very compact
- Very high ripple current capability
- High reliability
- Very low ESR at operating conditions above 50 °C
Applications
- Servo drives
- Frequency converters
- Solar inverters
- Medical appliances
Technical specifications
| Anschluss | Snap-in | |
| Ausführung | Polar | |
| Bauform | radial | |
| Durchmesser | 30 mm | |
| ESR (Äquivalenter Serienwiderstand) | 85 mΩ | |
| Kapazität | 1000 µF | |
| Länge | 35 mm | |
| max. Temperatur | 105 °C | |
| min. Temperatur | -40 °C | |
| Nennspannung (DC) | 200 V | |
| Rastermaß | 10 mm | |
| Rippelstrom | 2 A | |
| Toleranz | ±20 % |
Download
Logistics
| Ursprungsland | HU |
| Zolltarifnummer | 85322200 |
| Originalverpackung | Karton mit 80 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
