B82725A2202N001 | TDK (EPCOS)
Power line choke, radial, 18 mH, 2 A, B82725A2202N001
Unit Price (€ / pc.)
5.0813 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Power line choke, B82725A2202N001, EPCOS
Features
- High resonance frequency due to special winding technique
- Suitable for wave soldering
- Design complies with EN 60938-2
- Approx. 1% stray inductance for symmetrical interference suppression
- RoHS-compatible
Applications
- Suppression of common-mode interferences
- Switch-mode power applications
- Electronic ballasts in lamps
- Power inverters
Technical specifications
| Ausführung | Netzleitungsdrossel | |
| Bauform | radial | |
| Breite | 42.4 mm | |
| Gleichstrom | 2 A | |
| Gleichstromwiderstand | 330 mΩ | |
| Höhe | 25 mm | |
| Induktivität | 18 mH | |
| Länge | 44 mm | |
| Messfrequenz | 10 kHz | |
| Toleranz | ±30 % |
Download
Logistics
| Ursprungsland | HU |
| Zolltarifnummer | 85045000 |
| Originalverpackung | Karton mit 160 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
