B82734R2232B030 | TDK (EPCOS)
Power line choke, radial, 15 mH, 2.3 A, B82734R2232B030
Unit Price (€ / pc.)
2.5585 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
Power line choke, B82734R2232B030, EPCOS
Features
- High resonance frequency due to 2-section winding
- Suitable for wave soldering
- Design complies with EN 60938-2
- Low whirring noise
- High pulse strength
Applications
- Suppression of common-mode and differential-mode interferences
- Electronic ballasts for lamps
- Switch-mode power applications
Technical specifications
| Ausführung | Netzleitungsdrossel | |
| Bauform | radial | |
| Breite | 31 mm | |
| Gleichstrom | 2.3 A | |
| Gleichstromwiderstand | 185 mΩ | |
| Höhe | 21 mm | |
| Induktivität | 15 mH | |
| Länge | 32.5 mm | |
| Messfrequenz | 10 kHz | |
| Toleranz | -30/+50 % |
Download
Logistics
| Ursprungsland | HU |
| Zolltarifnummer | 85045000 |
| Originalverpackung | Karton mit 400 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate |
