B88069X3013T303 | TDK (EPCOS)
2 electrode arrester, SMD, 140 V, 500 A, ceramic, B88069X3013T303
Unit Price (€ / pc.)
0.6783 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
4,069.80 € *
Price list
Quantity
Price per unit*
6000 pcs.
0.6783 €
18000 pcs.
0.6307 €
*incl. VAT plus shipping costs
**Subject to prior sale
Surge arrester, B88069X3013T303, EPCOS
The B88069X3013T303 has been especially designed to meet data transmission protection requirements. The optimized design features a high level of protection against fast rising transients usually caused by lightning disturbances. For use in high frequency data lines, offers ultra low capacitances and shows only marginally signal losses up to high frequencies. Extremely reliable and is able to withstand high surge currents without destruction.
Features
- Small size
- Fast response time
- High current capability
- Stable performance over life
- Low capacitance and insertion loss
Applications
- Telecommunication
- CCTV
- Switching power supply
Technical specifications
| Bauform | SMD | |
| Ansprechspannung | 140 V | |
| Ableitstoßstrom | 500 A | |
| Anzahl der Ableiter | 2 | |
| Gehäusematerial | Keramik |
Download
Logistics
| Zolltarifnummer | 85363090 |
| Originalverpackung | Rolle mit 3.000 Stück |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
