B59101P1120A062 | TDK (EPCOS)

PTC thermistor, 13 Ω (13R), 120 °C, 25 %, B59101P1120A062

Order No.: 82E3000
EAN: 4099879981691
MPN:
B59101P1120A062
B59101P1120A62
Series: B59x
B59101P1120A062 TDK (EPCOS) PTC Thermistors
Image may differ
Unit Price (€ / pc.)
3.1416 € *
Available: 682 pcs.
Leadtime: 10 Weeks **
Total Price:
3.14 € *
Price list
Quantity
Price per unit*
1 pcs.
3.1416 €
10 pcs.
1.9635 €
50 pcs.
1.7136 €
250 pcs.
1.4875 €
1000 pcs.
1.2971 €
*incl. VAT plus shipping costs
**Subject to prior sale

SMD PTC thermistors, type TDK/Epcos B59.

In plastic mold, suitable for overload and short-circuit protection, with tinned leads for flow and reflow soldering

Operating voltage 30 V/60 °C and reference temperature of 120 °C, type B59101../B59201../B59301.

Technical specifications
ohmscher Widerstand 13 Ω
Ansprechtemperatur 120 °C
Bauform SMD 3225
max. Temperatur 125 °C
min. Temperatur -40 °C
Montage SMD
Nennspannung (AC) 30 V
Nennspannung (DC) 30 V
Nennstrom 170 A
Schaltstrom 355 mA
Toleranz ±25 %
Logistics
Ursprungsland CN
Zolltarifnummer 85332100
Originalverpackung Rolle mit 1.000 Stück
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
