SIM Card Connectors, 2174803-2, TE Connectivity
Module Type: SIM (Security Identity Module), Compatible Card: 3FF SIM, Connector & Contact Terminates To: Printed Circuit Board, Product Type: Connector, Card Insertion Style: Normal Insertion, Number of Positions: 6, Number of Loaded Positions: 6, Current Rating (Max): 0.5 A, Voltage Rating: 10 VAC, Ejector Type: Push-Push, Shell Material: Stainless Steel, Contact Base Material: Copper Alloy, Contact Current Rating (Max): 0.5 A, Connector Stabilization Ribs: Without, PCB Mounting Style: Surface Mount, Connector Mounting Type: Board Mount, Contact Retention: No, Centerline (Pitch): 2.54 mm, Housing Material: Thermoplastic, Height Above PC Board: 1.3 mm, Operating Temperature Range: -30 – 85 °C, Durability Rating: 1500 Cycles, Circuit Application: Signal, UL Flammability Rating: UL 94V-0, Packaging Method: Tape & Reel
