1-1478907-0 | TE Connectivity

SMA plug 50 Ω, RG-141A, RG-58C, URM-43, URM-76, solder connection, straight, 1-1478907-0

Order No.: 37P2304
EAN: 4099889829921
MPN:
1-1478907-0
Series: SMA
TE Connectivity
1-1478907-0 TE Connectivity Coaxial Connectors
Image may differ

As a private customer, you can buy this item as soon as we have it back in stock.

RF Coaxial connector, 1-1478907-0, TE Connectivity

Connector Product Type: Connector Assembly, RF Interface: SMA, RF Connector Style: Plug, Compatible With RF Cable Type: KX 15, RG 141A, RG 58C, RG 76, URM 43, Connector System: Cable-to-Cable, Number of Positions: 1, Number of Coaxial Contacts: 1, Impedance: 50 Ω, Cable Connector Orientation: Straight, Body Material: Stainless Steel, Body Material Finish: Plated, Body Plating Material: Gold, RF Connector Center Contact Underplating Material: Copper, RF Connector Center Contact Plating Material: Gold, RF Connector Center Contact Material: Brass, Termination Method to Wire & Cable: MIL-Clamp, RF Connector Coupling Mechanism: Threaded, Detent: Without, Product Length: 20.5 mm, RF Connector Mated Outer Diameter (Approximate): 6.35 mm, Operating Temperature Range: -65 – 165 °C, Operating Frequency: 26 GHz, Packaging Quantity: 100, Packaging Method: Box, Gasket Material: Silicone Rubber, Dielectric Material: PTFE

Technical specifications
Ausführung Stecker
Bauform gerade
Impedanz 50 Ω
Kabelgruppe RG-141A, RG-58C, URM-43, URM-76
Kontaktanschluss Lötanschluss
Kontaktmaterial Messing
Steckverbinder SMA
Logistics
Ursprungsland PT
Zolltarifnummer 85366910
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
