1-1903128-1 | TE Connectivity
Plug housing, 22 pole, pitch 2 mm, straight, black, 1-1903128-1
Unit Price (€ / pc.)
3.5462 € *
Available: 0 pcs.
Available in 5 Days: 1,830 pcs.
Leadtime: 20 Weeks **
Total Price:
3.55 € *
Price list
Quantity
Price per unit*
1 pcs.
3.5462 €
10 pcs.
3.2606 €
50 pcs.
2.9393 €
100 pcs.
2.6418 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB Connection System, 1-1903128-1, TE Connectivity
Wire-to-Panel, Wire & Cable, 22 Position
Technical Data
- Connector Mounting Type: Panel Mount
- Contact Type: Male
- Housing Material: Polyester GF
- Housing Color: black
- Number of positions: 22
- Operating Temperature Range: -55 – 105 °C [-67 – 221 °F]
- Centerline (Pitch): 2 mm
- Row-to-Row Spacing: 3.3 mm [0.129 in]
- Sealable: No
- Contact Layout: Matrix
Technical specifications
| Anschluss | Crimpanschluss | |
| Anzahl der Reihen | 2 | |
| Ausführung | Steckergehäuse | |
| Bestückung | unbestückt | |
| Brechbar | No | |
| Farbe | schwarz | |
| Kontaktart | Tab | |
| Nennspannung | 150 V | |
| Orientierung | gerade | |
| Polzahl | 22-polig | |
| Rastermaß | 2 mm | |
| Verriegelung | Nein |
Download
Logistics
| Ursprungsland | TH |
| Zolltarifnummer | 85389091 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
