1-1971875-7 | TE Connectivity
Socket housing, 15 pole, pitch 6 mm, straight, natural, 1-1971875-7
Unit Price (€ / pc.)
1.9159 € *
Available: 0 pcs.
Leadtime: 15 Weeks **
Total Price:
1.92 € *
Price list
Quantity
Price per unit*
1 pcs.
1.9159 €
10 pcs.
1.7374 €
50 pcs.
1.5708 €
100 pcs.
1.4161 €
*incl. VAT plus shipping costs
**Subject to prior sale
Receptacle housing, front panel mount, triple-row.
Housing lock CPA, flame retardant to UL 94 V-0, for applications with higher current and signal levels, increased functional safety by means of 3 types of locking mechanism, snap-lock (with acoustic feedback when snapped in securely, side fins around the snap-lock elements to prevent pinching of the wires), optional housing lock (CPA) and optional contact lock (TPA), 6.0 mm grid, single/double row or matrix. Rated voltage: 600 V AC/DC. Rated current: max. 20 A. Housing material: PBT, UL 94 V-0. Contacts: tinned copper alloy. Operating temperatures: - 55 to +105 °C. Certifications: cURus.
Technical attributes (type, dimensions (A,B,C)): 1-1971875-7, 15-pole, 33.7 mm, 39.5 mm, 31.3 mm
Technical specifications
| Connection | Crimpanschluss | |
| Number of rows | 3 | |
| Version | Buchsengehäuse | |
| Additional parts | unbestückt | |
| Breakable | No | |
| Colour | natur | |
| Contact type | Tab | |
| Rated voltage | 600 V | |
| Orientation | gerade | |
| Pin number | 15-polig | |
| Grid | 6 mm | |
| Type of locking | Ja |
Download
Logistics
| Country of origin | IN |
| Customs tariff number | 85472000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
