1586853-1 | TE Connectivity
Socket housing, 9 pole, pitch 6.35 mm, straight, natural, 1586853-1
Order No.: 35P5019
EAN: 4099889936599
MPN:
1586853-1
Unit Price (€ / pc.)
0.7854 € *
Available: 0 pcs.
Leadtime: 16 Weeks **
PCB Connection System, 1586853-1, TE Connectivity
Wire-to-Panel, Wire-to-Wire, Wire & Cable, 9 Position
Technical Data
- Connector Mounting Type: Panel Mount
- Contact Type: Male
- Housing Material: Nylon
- Housing Color: natural
- Number of positions: 9
- Operating Temperature Range: -55 – 105 °C [-67 – 221 °F]
- Centerline (Pitch): 6.35 mm
- Row-to-Row Spacing: 6.35 mm [0.25 in]
- Sealable: No
- Contact Layout: Matrix
Technical specifications
| Connection | Crimpanschluss | |
| Number of rows | 3 | |
| Version | Buchsengehäuse | |
| Additional parts | unbestückt | |
| Breakable | No | |
| Colour | natur | |
| Contact type | Buchse/Stift | |
| Rated voltage | 600 V | |
| Orientation | gerade | |
| Pin number | 9-polig | |
| Grid | 6.35 mm | |
| Type of locking | Ja |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85389011 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
