2232511-7 | TE Connectivity
Connector, 7 pole, pitch 5 mm, straight, natural, 2232511-7
Unit Price (€ / pc.)
2.2729 € *
Available: 0 pcs.
Available in 5 Days: 460 pcs.
Leadtime: 20 Weeks **
Total Price:
2.27 € *
Price list
Quantity
Price per unit*
40 pcs.
2.2729 €
250 pcs.
1.8207 €
*incl. VAT plus shipping costs
**Subject to prior sale
Tab header , 2232511-7, TE Connectivity
PCB Mount header, Vertical, Wire-to-Board, 7 Position, 5 mm centerline, Fully shrouded, Tin, Through Hole-Solder, Power, Natural.
Technical specifications
| Connection | solder connection | |
| Connection plating | tin-plated | |
| Number of rows | 1 | |
| Version | connector | |
| Additional parts | equipped | |
| Colour | natural | |
| Contact type | tab | |
| contact surface | tin-plated | |
| Rated voltage | 250 V | |
| Rated current | 16 A | |
| Orientation | straight | |
| Pin number | 7 pole | |
| Grid | 5 mm | |
| Type of locking | Yes |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85366930 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
