1986711-2 | TE Connectivity
PCB terminal, 2 pole, pitch 5 mm, AWG 30-12, 16 A, screw connection, green, 1986711-2
Order No.: 38P7478
EAN: 4099891039462
MPN:
1986711-2
Unit Price (€ / pc.)
2.8322 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
2.83 € *
Price list
Quantity
Price per unit*
1 pcs.
2.8322 €
10 pcs.
2.5823 €
50 pcs.
2.3205 €
100 pcs.
2.0825 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal block, 1986711-2, TE Connectivity
Wire Protection: With, Terminal Block Connector Type: Header, Connector System: Wire-to-Board, Connector & Contact Terminates To: Printed Circuit Board, Threaded Flange: Without, Number of Positions: 2, Number of Rows: 2, Wire Entry Angle: Side, Current Rating (Max): 16 A, Voltage Rating: 300 VAC, Interlock: Without, Contact Base Material: Copper Alloy, Contact Current Rating (Max): 16 A, Screw Flange: Without, Connector Mounting Type: Board Mount, Housing Material: Polyamide, Centerline (Pitch): 5 mm, PCB Tail Length: 3.5 mm, Wire Size: 30 – 12 AWG, Wire Size: 0.05 – 3 mm², Operating Temperature Range: -40 – 110 °C, Circuit Application: Power & Signal.
Technical specifications
| Connection | screw connection | |
| AWG cross-section | AWG 30-12 | |
| Colour | green | |
| Cable cross-section | 0.05-3.0 mm² | |
| Rated voltage | 300 V | |
| Rated current | 16 A | |
| Pin number | 2 pole | |
| Grid | 5 mm |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85366910 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
