282897-5 | TE Connectivity
PCB terminal, 9 pole, pitch 5.08 mm, AWG 30-12, 17.5 A, cage clamp, green, 282897-5
Order No.: 71P7056
EAN: 4099891630928
MPN:
282897-5
Unit Price (€ / pc.)
61.7729 € *
Available: 0 pcs.
Leadtime: 11 Weeks **
Total Price:
61.77 € *
Price list
Quantity
Price per unit*
1 pcs.
61.7729 €
5 pcs.
57.4532 €
10 pcs.
52.8479 €
25 pcs.
48.6234 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal, 282897-5, TE Connectivity
PCB Terminal block, Header, Wire-to-Board, 9 Position, 5.08 mm Centerline, 3 Row, Side wire entry angle, 30 - 12 AWG Wire size.
Applications
- Industrial control
- HVAC equipment and control
- Communications equipment
- Test and measurement
- Fire and security
Technical specifications
| Anschluss | Käfigklemme | |
| AWG-Leiterquerschnitt | AWG 30-12 | |
| Breite | 33.7 mm | |
| Farbe | grün | |
| Höhe | 35.6 mm | |
| Leiterquerschnitt | 0,05-3 mm² | |
| Nennspannung | 300 V | |
| Nennstrom | 17.5 A | |
| Polzahl | 9-polig | |
| Rastermaß | 5.08 mm |
Download
Logistics
| Ursprungsland | IT |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
