2834082-2 | TE Connectivity
PCB terminal, 3 pole, pitch 5 mm, AWG 28-12, 20 A, spring-clamp connection, gray, 2834082-2
Order No.: 39P9500
EAN: 4099891039677
MPN:
2834082-2
Unit Price (€ / pc.)
0.9163 € *
Available: 0 pcs.
Available in 5 Days: 3,090 pcs.
Leadtime: 26 Weeks **
Total Price:
0.92 € *
Price list
Quantity
Price per unit*
100 pcs.
0.9163 €
500 pcs.
0.8687 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal block, 2834082-2, TE Connectivity
Terminal Block Connector Type: Receptacle, Connector System: Wire-to-Board, Sealable: No, Connector & Contact Terminates To: Printed Circuit Board, Number of Positions: 3, Number of Rows: 1, Wire Entry Angle: Side, Current Rating (Max): 20 A, Voltage Rating: 300 VAC, Color: Gray, Contact Base Material: Copper, Contact Current Rating (Max): 20 A, Mounting Angle: Vertical, Housing Material: High Temperature Nylon or Polyester, Wire Size: 28 – 12 AWG, Operating Temperature Range: -40 – 105 °C, Circuit Application: Power & Signal.
Technical specifications
| Connection | spring-clamp connection | |
| AWG cross-section | AWG 28-12 | |
| Colour | gray | |
| Rated voltage | 300 V | |
| Rated current | 20 A | |
| Pin number | 3 pole | |
| Grid | 5 mm |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85366930 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
