284514-5 | TE Connectivity
PCB terminal, 5 pole, pitch 3.5 mm, AWG 30-14, 11 A, pin, green, 284514-5
Order No.: 38P7460
EAN: 4099891039288
MPN:
284514-5
Unit Price (€ / pc.)
2.4752 € *
Available: 0 pcs.
Leadtime: On Request **
PCB terminal block, 284514-5, TE Connectivity
Header Type: Shrouded, Terminal Block Connector Type: Header, Connector System: Wire-to-Board, Connector & Contact Terminates To: Printed Circuit Board, Threaded Flange: Without, Number of Positions: 5, Number of Rows: 1, Current Rating (Max): 11 A, Voltage Rating: 300 VAC, Interlock: Without, Contact Base Material: Phosphor Bronze, Contact Current Rating (Max): 11 A, Screw Flange: Without, Connector Mounting Type: Board Mount, Housing Material: PA 66, Centerline (Pitch): 3.5 mm, PCB Tail Length: 3.4 mm, Wire Size: 30 – 14 AWG, Wire Size: .05 – 2 mm², Operating Temperature Range: -40 – 105 °C, Circuit Application: Power & Signal.
Technical specifications
| Connection | pin | |
| AWG cross-section | AWG 30-14 | |
| Colour | green | |
| Cable cross-section | 0.05-2.0 mm² | |
| Rated voltage | 300 V | |
| Rated current | 11 A | |
| Pin number | 5 pole | |
| Grid | 3.5 mm |
Download
Logistics
| Country of origin | US |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
