284517-8 | TE Connectivity
PCB terminal, 8 pole, pitch 3.81 mm, AWG 30-14, 11 A, pin, green, 284517-8
Order No.: 38P7462
EAN: 4099891039301
MPN:
284517-8
Unit Price (€ / pc.)
2.0111 € *
Available: 0 pcs.
Leadtime: On Request **
PCB terminal block, 284517-8, TE Connectivity
Header Type: Shrouded, Terminal Block Connector Type: Header, Connector System: Wire-to-Board, Connector & Contact Terminates To: Printed Circuit Board, Threaded Flange: Without, Number of Positions: 8, Number of Rows: 1, Current Rating (Max): 11 A, Voltage Rating: 300 VAC, Interlock: Without, Contact Base Material: Phosphor Bronze, Contact Current Rating (Max): 11 A, Screw Flange: Without, Connector Mounting Type: Board Mount, Housing Material: PA 66, Centerline (Pitch): 3.81 mm, PCB Tail Length: 3.4 mm, Wire Size: 30 – 14 AWG, Wire Size: 0.05 – 2 mm², Operating Temperature Range: -40 – 105 °C, Circuit Application: Power & Signal.
Technical specifications
| Anschluss | Stift | |
| AWG-Leiterquerschnitt | AWG 30-14 | |
| Farbe | grün | |
| Leiterquerschnitt | 0,05-2,0 mm² | |
| Nennspannung | 300 V | |
| Nennstrom | 11 A | |
| Polzahl | 8-polig | |
| Rastermaß | 3.81 mm |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
