796949-7 | TE Connectivity
PCB terminal, 7 pole, pitch 5.08 mm, AWG 30-12, 17.5 A, screw connection, black, 796949-7
Order No.: 38P7477
EAN: 4099891039455
MPN:
796949-7
Unit Price (€ / pc.)
1.4161 € *
Available: 0 pcs.
Leadtime: 10 Weeks **
PCB terminal block, 796949-7, TE Connectivity
Wire Protection: With, Terminal Block Connector Type: Header, Connector System: Wire-to-Board, Connector & Contact Terminates To: Printed Circuit Board, Closed End: Without, Number of Positions: 7, Number of Rows: 1, Wire Entry Angle: Side, Current Rating (Max): 17.5 A, Voltage Rating: 300 VAC, Interlock: With, Contact Base Material: Brass, Contact Current Rating (Max): 17.5 A, Screw Flange: Without, Connector Mounting Type: Board Mount, Housing Material: PA 66, Centerline (Pitch): 5.08 mm, PCB Tail Length: 3.5 mm, Wire Size: 30 – 12 AWG, Wire Size: 0.05 – 3 mm², Operating Temperature Range: -40 – 110 °C, Circuit Application: Power & Signal, Marking Color: White.
Technical specifications
| Connection | Schraubanschluss | |
| AWG cross-section | AWG 30-12 | |
| Colour | schwarz | |
| Cable cross-section | 0,05-3,0 mm² | |
| Rated voltage | 300 V | |
| Rated current | 17.5 A | |
| Pin number | 7-polig | |
| Grid | 5.08 mm |
Download
Logistics
| Country of origin | US |
| Customs tariff number | 85366910 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Blei |
