1SNK806723R0000 | TE Connectivity
Modular terminal block, push-in spring connection, 4.0 mm², 2 pole, 30 A, 8 kV, gray, 1SNK806723R0000
Unit Price (€ / pc.)
27.9412 € *
Available: 0 pcs.
Available in 5 Days: 1,340 pcs.
Leadtime: 19 Weeks **
Total Price:
27.94 € *
Price list
Quantity
Price per unit*
4 pcs.
27.9412 €
16 pcs.
26.3109 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB Terminal, 1SNK806723R0000, TE Connectivity
The 1SNK806723R0000 is a screw clamp terminal block that offers rationalized functions and accessories while serving a large scope of applications. Asymmetrical design avoid mounting and wiring errors. This product has Intuitive codification, simplified catalogs and large technical data base.
Features
- Easy to install
- Optimized logistics
Technical specifications
| Connection | push-in spring connection | |
| Version | modular terminal block | |
| AWG cross-section | AWG 10 | |
| Rated Voltage | 1000 V | |
| Rated surge voltage | 8 kV | |
| Width | 6 mm | |
| Colour | gray | |
| Height | 20.6 mm | |
| Length | 36.3 mm | |
| Cable cross-section | 4.0 mm² | |
| Rated current | 30 A | |
| Pin number | 2 pole |
Download
Logistics
| Country of origin | FR |
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
