2271555-1 | TE Connectivity

Name: Terminal block, quick connection, 0.08-2.5 mm², 1 pole, 20 A, 8 kV, gray, 2271555-1
Brand: TE Connectivity
SKU: 71P6105
Availability: InStock

Terminal block, quick connection, 0.08-2.5 mm², 1 pole, 20 A, 8 kV, gray, 2271555-1

Order No.: 71P6105

EAN: 4099891649845

MPN:

2271555-1

Image may differ

Key Specification:

Version spring terminal block

Pin number 1 pole

Cable cross-section 0.08-2.5 mm²

AWG cross-section AWG 28 to 12

Ordering Information:

not to be sold to private customers

Download Datasheet Technical specifications

Unit Price (€ / pc.)

1.2257 € *

Available in 5 Days: 2,997 pcs. - if ordered today

Total Price:

245.14 € *

Price list

Quantity

Price per unit*

200 pcs.

1.2257 €

400 pcs.

1.1900 €

*incl. VAT plus shipping costs

Subject to prior sale

Description

Terminal block, 2271555-1, TE Connectivity

Spring terminal block, 1 position, Quick connect, Standard, Matte tin, DIN Rail, UL 94V-0.

Technical specifications

Filter	Property	Value
	Version	spring terminal block
	Pin number	1 pole
	Cable cross-section	0.08-2.5 mm²
	AWG cross-section	AWG 28 to 12
	Rated surge voltage	8 kV
	Rated current	20 A
	Rated Voltage	600 V
	Length	48.8 mm
	Width	5.15 mm
	Height	35.4 mm
	Connection	quick connection
	Colour	gray
