KSG106M250S1K5H15K | Teapo
Electrolytic capacitor, 10 µF, 250 V (DC), ±20 %, radial, pitch 5 mm, Ø 10 mm, KSG106M250S1K5H15K
Unit Price (€ / pc.)
1.0591 € *
Available: 1,260 pcs.
Next delivery: 1,400 pcs. on 2025-05-13
Leadtime: 30 Weeks **
Total Price:
1.06 € *
Price list
Quantity
Price per unit*
1 pcs.
1.0591 €
10 pcs.
0.6664 €
50 pcs.
0.4760 €
250 pcs.
0.3927 €
1000 pcs.
0.3451 €
*incl. VAT plus shipping costs
**Subject to prior sale
Electrolytic capacitor, insulated aluminum can, type SG.
Wire connections on one side, for vertical PCB mounting. Useful life 5000 h at +105 °C
Rated voltage 250 VDC, type SG 250.
Technical specifications
| Ausführung | Polar | |
| Bauform | radial | |
| Durchmesser | 10 mm | |
| Kapazität | 10 µF | |
| Länge | 15 mm | |
| max. Temperatur | 105 °C | |
| min. Temperatur | -40 °C | |
| Nennspannung (DC) | 250 V | |
| Rastermaß | 5 mm | |
| Rippelstrom | 850 mA | |
| Toleranz | ±20 % |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85322200 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
