KSG107M450S1A5Q40K | Teapo
Electrolytic capacitor, 100 µF, 450 V (DC), ±20 %, radial, pitch 10 mm, Ø 22 mm, KSG107M450S1A5Q40K
Unit Price (€ / pc.)
5.6287 € *
Available: 179 pcs.
Leadtime: 26 Weeks **
Total Price:
5.63 € *
Price list
Quantity
Price per unit*
1 pcs.
5.6287 €
10 pcs.
4.9623 €
100 pcs.
4.3435 €
250 pcs.
4.1769 €
1000 pcs.
3.9151 €
*incl. VAT plus shipping costs
**Subject to prior sale
Electrolytic capacitor, insulated aluminum can, type SG.
Wire connections on one side, for vertical PCB mounting. Useful life 5000 h at +105 °C
Rated voltage 450 VDC, type SG 450.
Technical specifications
| Version | polar | |
| Design | radial | |
| diameter | 22 mm | |
| Capacity | 100 µF | |
| Length | 40 mm | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -40 °C | |
| Rated voltage (DC) | 450 V | |
| Grid | 10 mm | |
| Ripple current | 580 mA | |
| Tolerance | ±20 % |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85322200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
