SLG157M250S1A5Q25K | Teapo
Electrolytic capacitor, 150 µF, 250 V (DC), ±20 %, radial, pitch 10 mm, Ø 22 mm, SLG157M250S1A5Q25K
Unit Price (€ / pc.)
3.3915 € *
Available: 356 pcs.
Next delivery: 100 pcs. on 2025-01-23
Leadtime: On Request **
Total Price:
3.39 € *
Price list
Quantity
Price per unit*
1 pcs.
3.3915 €
10 pcs.
2.7370 €
100 pcs.
2.3205 €
250 pcs.
1.9992 €
1000 pcs.
1.7493 €
*incl. VAT plus shipping costs
**Subject to prior sale
Electrolytic capacitor in aluminum can, type LG.
With insulated package and snap-in connection
Rated voltage 250 VDC, type LG 250.
Technical specifications
| Connection | snap-in | |
| Version | polar | |
| Design | radial | |
| diameter | 22 mm | |
| Capacity | 150 µF | |
| Length | 25 mm | |
| max. operating temperature | 105 °C | |
| min. operating temperature | -25 °C | |
| Rated voltage (DC) | 250 V | |
| Grid | 10 mm | |
| Ripple current | 650 mA | |
| Tolerance | ±20 % |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85322200 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
