100007167 | Telegärtner
LC-plug, multimode, ceramic, purple, 100007167
Unit Price (€ / pc.)
6.9496 € *
Available: 0 pcs.
Leadtime: 7 Weeks **
J08071A0052 from Telegärtner at Bürklin Elektronik
Find detailed information about the product on our site J08071A0052 from Telegärtner. The manufacturer description for this product is: LC Duplex Coupling, Multimode, Ceramics sleeve, Plastic housing, Snap-in or Screw mounting, PurpleMore information about J08071A0052
- Versions in singlemode and multimode. For fiber mounting 0.9 mm and cable mounting up to 3.2 mm. Multimode as 50 µ, 62.5 µ, 200 µ and 980 µ. Singlemode as 9 µ.
- Designation: LC Duplex Coupling, Multimode, Ceramics sleeve, Plastic housing
- Installation type: Snap-in or Screw mounting
- Installation dimension: Z77
- Housing color: Purple
Technical features
- Mounting type: Screw/Snap in
- Color: Other
- Suitable for fiber type: Multimode
- Connector type Connection 1: LC-Duplex
- Connector type Connection 2: LC-Duplex
- Sleeve material: Ceramics
- Housing material: Plastic
Technical specifications
| Connection | screw connection | |
| Version | LC-plug | |
| Colour | purple | |
| Chamfer type | multimode | |
| Ferrule | ceramic |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85367000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
