CD4029BE | Texas Instruments
CMOS Presetable Up/Down Counter, PDIP-16, Texas Instruments CD4029BE
Unit Price (€ / pc.)
0.5712 € *
Available: 118 pcs.
Leadtime: On Request **
Total Price:
2.86 € *
Price list
Quantity
Price per unit*
5 pcs.
0.5712 €
50 pcs.
0.4998 €
100 pcs.
0.4284 €
500 pcs.
0.4046 €
1000 pcs.
0.3570 €
*incl. VAT plus shipping costs
**Subject to prior sale
CMOS counter, CD4029BE, Texas Instruments
The CD4029BE is a consists of a four-stage binary or BCD-decade up/down counter with provisions for look-ahead carry in both counting modes. The inputs consist of a single CLOCK, CARRY-IN\ (CLOCK ENABLE\), BINARY/DECADE, UP/DOWN, PRESET ENABLE, and four individual JAN signals, Q1, Q2, Q3, Q4 and a CARRY OUT\ signal are provided as outputs. This product has a high preset enable that allows information on the JAM INPUTS to preset the counter to any state asynchronously with the clock.
Features
- Binary or decade up/down counting
- Standardized symmetrical output characteristics
- BCD outputs in decade mode
Applications
- Programmable binary and decade counting/frequency synthesizers BCD output
- Analog to digital and digital to analog conversion
- Up/Down binary counting
- Magnitude and sign generation
- Difference counting
Technical specifications
| Output current | 1.5 mA | |
| Input voltage | 18 V | |
| Enclosure | PDIP-16 | |
| max. operating temperature | 125 °C | |
| min. operating temperature | -55 °C | |
| Assembly | THT | |
| Product type | CMOS Presetable Up/Down Counter |
Download
Logistics
| Country of origin | MX |
| Customs tariff number | 85423390 |
| MSL | MSL 1 |
| Original Packaging | Stange mit 25 Stück |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
