SN74HC74 | Texas Instruments
Dual D-Type Positive-Edge-Triggered Flip-Flop, PDIP-14, Texas Instruments SN74HC74
Unit Price (€ / pc.)
0.8687 € *
Available: 0 pcs.
Available in 5 Days: 400 pcs.
Leadtime: 8 Weeks **
Total Price:
0.87 € *
Price list
Quantity
Price per unit*
100 pcs.
0.8687 €
500 pcs.
0.7616 €
1000 pcs.
0.6902 €
*incl. VAT plus shipping costs
**Subject to prior sale
D-type flip-flops, SN74HC74, Texas Instruments
The SN74HC74 contains two independent D-type positive-edge-triggered flip-flops with asynchronous preset and clear pins for each.
Features
- Buffered inputs
- Wide operating voltage range: 2 V to 6 V
- Supports fanout up to 10 LSTTL loads
- Significant power reduction compared to LSTTL logic ICs
Applications
- Convert a momentary switch to a toggle switch
- Divide a clock signal by 2 or 4
Technical specifications
| Output current | 5.2 mA | |
| Input voltage | 6 V | |
| Enclosure | PDIP-14 | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -40 °C | |
| Assembly | THT | |
| Product type | Dual D-Type Positive-Edge-Triggered Flip-Flop |
Download
Logistics
| Country of origin | MY |
| Customs tariff number | 85423390 |
| MSL | MSL 1 |
| Original Packaging | Bar with 25 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
