A08 T30 HWS | TRACO POWER
AC axial fan, 240 V, 80 x 80 x 25 mm, 28.2 m³/h, 29 dB, slide bearing, TRACO POWER A08 T30 HWS
Order No.: 82B4600
EAN: 4099889479379
MPN:
A08 T30 HWS
Unit Price (€ / pc.)
24.2165 € *
Available: 0 pcs.
Leadtime: 12 Weeks **
AC Axial fan, A08 T30 HWS, TRACO
The A08 T30 HWS axial AC fan is a type of fan that blow air along the axis of the fan that is, the fancurved blades force air to move in parallel with the shaft on which the blades rotate. This fan can produce variable airflow and create higher flow rates than centrifugal fan.
Features
- Housing die cast aluminum
- Impedance protected
- Impeller thermoplastic - UL 94V-0
- Cable connection 300mm stranded wire or flat plug connection AMP6.9
Technical specifications
| Ausführung | AC-Axiallüfter | |
| Breite | 80 mm | |
| Drehzahl | 2300 1/min | |
| Höhe | 80 mm | |
| Lagerart | Gleitlager | |
| Nennspannung | 240 V | |
| Schalldruckpegel | 29 db | |
| Tiefe | 25 mm | |
| Volumenstrom | 28.2 m³/h |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 84145925 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
