TDL 2-1210 | TRACO POWER
DC converter, 9-18 VDC, 2 W, 1 output, 3.3 VDC, 80 % efficiency, TDL 2-1210
Unit Price (€ / pc.)
19.5993 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
19.60 € *
Price list
Quantity
Price per unit*
1 pcs.
19.5993 €
10 pcs.
17.6239 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TDL 2-1210
The TDL 2 series with 2:1 input voltage range is a selection of 2 Watt regulated dc/dc-converters. They come in a very compact DIP package (0.55 x 0.55 x 0.31 inch).
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 3,3 VDC | |
| Ausgangsstrom | 400 mA | |
| Bauform | DIP7 | |
| Breite | 14 mm | |
| Eingangsspannungsbereich | 9-18 VDC | |
| Höhe | 8 mm | |
| Isolationsspannung | 1.5 kV | |
| Länge | 14 mm | |
| Leistung | 2 W | |
| Wirkungsgrad | 80 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
