TDL 3-2422 | TRACO POWER
DC converter, 18-36 VDC, 3 W, 2 outputs, ±12 VDC, 86 % efficiency, TDL 3-2422
Unit Price (€ / pc.)
23.4430 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
23.44 € *
Price list
Quantity
Price per unit*
1 pcs.
23.4430 €
10 pcs.
21.0987 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TDL 3-2422
The TDL 3 series with 2:1 input voltage range is a selection of 3 Watt regulated dc/dc-converters. They come in a very compact DIP package (0.55 x 0.55 x 0.31 inch).
Technical specifications
| Anzahl der Ausgänge | 2 | |
| Ausgangsspannungsbereich | ±12 VDC | |
| Ausgangsstrom | 125 mA | |
| Bauform | DIP7 | |
| Breite | 14 mm | |
| Eingangsspannungsbereich | 18-36 VDC | |
| Höhe | 8 mm | |
| Isolationsspannung | 1.5 kV | |
| Länge | 14 mm | |
| Leistung | 3 W | |
| Wirkungsgrad | 86 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
