TDR 3-4823 | TRACO POWER
DC converter, 36-75 VDC, 3 W, 2 outputs, ±15 VDC, 83 % efficiency, TDR 3-4823
Unit Price (€ / pc.)
33.6056 € *
Available: 0 pcs.
Leadtime: 20 Weeks **
Total Price:
33.61 € *
Price list
Quantity
Price per unit*
1 pcs.
33.6056 €
10 pcs.
30.2617 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TDR 3-4823
The TDR-3 series is a family of compact 3 W dc/dc-converters with 2:1 input voltage ranges and tightly regulated output voltages even under no load conditions. The product is available in SMD-package or in DIP-package. They work with high efficiency over the full load range and come with a remote On/Off input. The usability in temperature ranges of up to 85°C, continuous short circuit protection and excellent immunity against environmental influences make these converters very reliable. A TDR-3 converter is the ideal solution for space critical high end applications in communication equipment, instrumentation and industrial electronics.
Technical specifications
| Anzahl der Ausgänge | 2 | |
| Ausgangsspannungsbereich | ±15 VDC | |
| Ausgangsstrom | 100 mA | |
| Bauform | DIP14 | |
| Breite | 12.8 mm | |
| Eingangsspannungsbereich | 36-75 VDC | |
| Höhe | 8.7 mm | |
| Isolationsspannung | 1.6 kV | |
| Länge | 18.9 mm | |
| Leistung | 3 W | |
| Wirkungsgrad | 83 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
