TEL 2-1210 | TRACO POWER
DC/DC converter, 9-18 VDC, 2 W, 1 output, 3.3 VDC, 73 % efficiency, TEL 2-1210
Unit Price (€ / pc.)
13.3280 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
13.33 € *
Price list
Quantity
Price per unit*
1 pcs.
13.3280 €
10 pcs.
11.9952 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TEL 2-1210
The TEL-2 series, comprising 28 models, is a range of isolated 2 Watt converters in a low profile DIP-16 package. Requiring only 3.25 cm² of space on the PCB they provide a complete DC/DC converter without need of any external components. Wide input range and tightly regulated output voltage qualifies these converters for many cost critical applications in industrial and consumer electronics.
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 3.3 VDC | |
| Output current | 500 mA | |
| Design | DIP16 | |
| Width | 13.7 mm | |
| Input voltage AC | 9-18 VDC | |
| Height | 8 mm | |
| Isolation voltage | 1.5 kV | |
| Length | 23.8 mm | |
| Power | 2 W | |
| efficiency | 73 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
