TEM 3-0512N | TRACO POWER
DC/DC converter, 4.5-5.5 VDC, 3 W, 1 output, 12 VDC, 78 % efficiency, TEM 3-0512N
Unit Price (€ / pc.)
12.8877 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
12.89 € *
Price list
Quantity
Price per unit*
1 pcs.
12.8877 €
10 pcs.
11.5906 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TEM 3-0512N
The TEM 3N series is a range of isolated dc/dc converters in a DIP-24 package. They offer tight output regulation and very low output noise. Operating temperature range is –40°C to +85°C. This product series provides a cost effective solution for many industrial or consumer electronics applications.
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 12 VDC | |
| Output current | 250 mA | |
| Design | DIP24 | |
| Width | 20 mm | |
| Input voltage AC | 4.5-5.5 VDC | |
| Height | 10 mm | |
| Isolation voltage | 1.5 kV | |
| Length | 32 mm | |
| Power | 3 W | |
| efficiency | 78 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
