TEN 10-11015WIRH | TRACO POWER
DC/DC converter, 36-160 VDC, 10 W, 1 output, 24 VDC, 88 % efficiency, TEN 10-11015WIRH
Unit Price (€ / pc.)
43.8634 € *
Available: 0 pcs.
Leadtime: 2 Weeks **
Total Price:
43.86 € *
Price list
Quantity
Price per unit*
1 pcs.
43.8634 €
10 pcs.
39.4723 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC Converter, TEN 10-11015WIRH, TRACO POWER
The TEN 10WIRH is a 10 watt railway-certified DC/DC converter with reinforced I/O isolation for highest reliability in harsh environments. The proven and certified design guarantees highest resistance against thermal shocks, moisture, mechanical shocks, and vibration. The TEN 10WIRH comes with additional EN 62368-1 safety approvals for IT equipment and EN 45545-2 certification for fire behavior. Thanks to its favorable operating temperature range of -40°C to +75°C without derating (depending on the model), the TEN 10WIRH presents a first choice for demanding applications.
Features
- Internal class A EMI filter
- Remote on/off function
- Undervoltage lockout (UVLO)
- Short-circuit protection (SCP)
- Overvoltage protection (OVP)
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 24 VDC | |
| Output current | 416 mA | |
| Design | DIP24 | |
| Width | 20.3 mm | |
| Input voltage AC | 36-160 VDC | |
| Height | 10.6 mm | |
| Isolation voltage | 3 kV | |
| Length | 31.8 mm | |
| Power | 10 W | |
| efficiency | 88 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
