TEN 3-4822 | TRACO POWER
DC converter, 36-75 VDC, 3 W, 2 outputs, ±12 VDC, 84 % efficiency, TEN 3-4822
Unit Price (€ / pc.)
20.3133 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
20.31 € *
Price list
Quantity
Price per unit*
1 pcs.
20.3133 €
10 pcs.
18.2903 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TEN 3-4822
The TEN 3 series of DC/DC converters, comprising 28 models, has been designed for a wide range of applications in industrial and communication systems. High efficiency allows an operating temperature range of –40°C to +85°C. Other features of these converters are internal filtering according to EN 55022-A and FCC, level A. Full SMD-design guarantees a high reliability of this product.
Technical specifications
| Anzahl der Ausgänge | 2 | |
| Ausgangsstrom | 125 mA | |
| Ausgangsspannungsbereich | ±12 VDC | |
| Eingangsspannungsbereich | 36-75 VDC | |
| Leistung | 3 W | |
| Wirkungsgrad | 84 % | |
| Bauform | DIP24 | |
| Isolationsspannung | 1.5 kV | |
| Länge | 31.8 mm | |
| Breite | 20.3 mm | |
| Höhe | 10.2 mm |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
