TEN 6-4823WIN-HI | TRACO POWER
DC/DC converter, 18-75 VDC, 6 W, 2 outputs, ±15 VDC, 84 % efficiency, TEN 6-4823WIN-HI
Unit Price (€ / pc.)
29.7024 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
29.70 € *
Price list
Quantity
Price per unit*
1 pcs.
29.7024 €
10 pcs.
26.7274 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TEN 6-4823WIN-HI
The TEN-6WIN series is designed for an optimized cost/performance ratio of DC/DC converters with output power of 6 Watt. General features like no minimum load requirement, overload protection, internal filter for EN55022 class A and high efficiency make these converters easy to design in. With the popular DIP-24 standard package they are also a drop in replacement for many cost critical applications.
Technical specifications
| Number of outputs | 2 | |
| Output voltage DC | ±15 VDC | |
| Output current | 200 mA | |
| Design | DIP24 | |
| Width | 20.3 mm | |
| Input voltage AC | 18-75 VDC | |
| Height | 10.2 mm | |
| Isolation voltage | 3 kV | |
| Length | 31.8 mm | |
| Power | 6 W | |
| efficiency | 84 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
