TES 1-0523V | TRACO POWER
DC/DC converter, 4.5-5.5 VDC, 1 W, 2 outputs, ±15 VDC, 80 % efficiency, TES 1-0523V
Unit Price (€ / pc.)
11.2098 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
11.21 € *
Price list
Quantity
Price per unit*
1 pcs.
11.2098 €
10 pcs.
10.0912 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TES 1-0523V
The TES-1V series are miniature, 1W DC/DC-converters with high isolation in a SMD package. With a new package design these converters are qualified for the higher temperatures requested by lead-free reflow solder processes. With the small footprint, these converters are the ideal solution for board level power distribution, mainly for applications in the industrial- and telecom field. For automated SMD production lines the devices can be supplied in standard tape and reel package.
Technical specifications
| Number of outputs | 2 | |
| Output voltage DC | ±15 VDC | |
| Output current | 34 mA | |
| Design | SMD | |
| Width | 8 mm | |
| Input voltage AC | 4.5-5.5 VDC | |
| Height | 8 mm | |
| Isolation voltage | 3 kV | |
| Length | 16.3 mm | |
| Power | 1 W | |
| efficiency | 80 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
