THB 10-2423 | TRACO POWER
DC converter, 18-36 VDC, 10 W, 2 outputs, ±15 VDC, 82 % efficiency, THB 10-2423
Order No.: 32C1839
EAN: 4099891310592
MPN:
THB 10-2423
Unit Price (€ / pc.)
71.7213 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
71.72 € *
Price list
Quantity
Price per unit*
1 pcs.
71.7213 €
10 pcs.
64.5337 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco THB 10-2423
The THB 10 series is a range of high performance DC/DC converter modules with double reinforced insulation system. It complies to latest medical safety standard IEC 60950-1 3rd edition for MOOP (Means of Operator Protection). The product comes in a 2”x1” industry standard package. All 12 models features wide 2:1 input voltage range and fully regulated output voltage. The converters offer an economical solution for demanding applications in industrial and medical instrumentation.
Technical specifications
| Anzahl der Ausgänge | 2 | |
| Ausgangsspannungsbereich | ±15 VDC | |
| Ausgangsstrom | 333 mA | |
| Bauform | DIP5 | |
| Breite | 25.4 mm | |
| Eingangsspannungsbereich | 18-36 VDC | |
| Höhe | 12 mm | |
| Isolationsspannung | 4 kV | |
| Länge | 50.8 mm | |
| Leistung | 10 W | |
| Wirkungsgrad | 82 % |
Download
Logistics
| Ursprungsland | TW |
| Zolltarifnummer | 85044095 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | No |
| Substanz Beschreibung | Blei |
