TMAP 2415S | TRACO POWER
DC/DC converter, 21.6-26.4 VDC, 1 W, 1 output, 15 VDC, 82 % efficiency, TMAP 2415S
Unit Price (€ / pc.)
9.3891 € *
Available: 0 pcs.
Leadtime: 14 Weeks **
Total Price:
9.39 € *
Price list
Quantity
Price per unit*
1 pcs.
9.3891 €
10 pcs.
8.4371 €
*incl. VAT plus shipping costs
**Subject to prior sale
DC/DC converters, Traco TMAP 2415S
The TMAP series is a range of 1 Watt DC/DC converters in compact SIP-7 package with overload and shorct circuit protection. An excellent efficiency allows these converters to operate up to +85°C without derating. In addition these converters offer a 3’000 VDC I/O isolation. This series is thus suitable for many industrial applications.
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 15 VDC | |
| Output current | 86 mA | |
| Design | SIP7 | |
| Width | 6 mm | |
| Input voltage AC | 21.6-26.4 VDC | |
| Height | 10 mm | |
| Isolation voltage | 3 kV | |
| Length | 11.5 mm | |
| Power | 1 W | |
| efficiency | 82 % |
Download
Logistics
| Country of origin | TW |
| Customs tariff number | 85044095 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
